Durability:
Accuracy:
Performance:
Well-Balanced & Lightweight Design:
Model | Actuation | Torque Range (Nm) | Torque Range (in-lbs) | Free Speed (rpm) | Weight (kg) | Weight (lb.) | Length (mm) | Length (in) | Side to Center Distance (mm) | Side to Center Distance (in) | Spindle Type | Sound Level dB(A) @ Free Speed | Inlet Location | Air Inlet (NPTF/NPT) | CFM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
41SA10LPQ4 | Lever + Push to Start | 1.7-9.0 | 15 - 80 | 1000 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA10PSQ4 | Push to Start | 1.7 - 9.0 | 15 - 80 | 1000 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA17LPQ4 | Lever + Push to Start | 1.7-6.8 | 15 - 60 | 1700 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA17PSQ4 | Push to Start | 1.7 - 6.8 | 15 - 60 | 1700 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA25LPQ4 | Lever + Push to Start | 1.7-4.5 | 15 - 40 | 2500 | 1.1 | 2.5 | 264 | 10.4 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA8LPQ4 | Lever + Push to Start | 1.7-11.3 | 15 - 100 | 800 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA8PSQ4 | Push to Start | 1.7 - 11.3 | 15 - 100 | 800 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
41SA10LPQ4-EU | Push to Start | 1.7 - 9.0 | 15 - 80 | 1000 | 1.2 | 2.7 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 30 |
