Vacuum Ready:
Durability:
Performance:
Model | Rated Power (hp) | Rated Power hp (kW) | Max Free Speed (rpm) | Exhaust | Output Thread | Orbit Diameter (in) | Orbit Diameter (mm) | Pad Diameter or Size (in) | Pad Diameter or Size (mm) | Pad Face | Vaccum Ready | Shroud Style | Weight (lbs) | Weight (kg) | Length (in) | Length (mm) | Vibration m/s² (uncertainty K) | Sound Pressure/ Power dBA | Min Hose Size (in) | Min Hose Size (mm) | Air Inlet (in) | Average Air Consumption (cfm) | Average Air Consumption (L/min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
4151 | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/16 | 5 | 6 | 150 | Vinyl | Yes | Short | 1.92 | 0.87 | 7.48 | 190 | 7.5 (uncertainty: 1.6) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4152 | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/32 | 2.5 | 6 | 150 | Vinyl | Yes | Short | 1.92 | 0.87 | 7.48 | 190 | 8.2 (uncertainty: 1.7) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4151-2 | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/16 | 5 | 6 | 150 | Vinyl | Yes | Short | 2.46 | 1.12 | 9.9 | 252 | 6.2 (uncertainty: 1) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4151-5 | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/16 | 5 | 5 | 125 | Vinyl | Yes | Short | 1.92 | 0.87 | 7 | 178 | 6.2 (uncertainty: 1) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4151-HL | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/16 | 5 | 6 | 150 | Hook and Loop | Yes | Short | 1.92 | 0.87 | 7.48 | 190 | 7 (uncertainty: 2.2) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4151-HL-2 | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/16 | 5 | 6 | 150 | Hook and Loop | Yes | Short | 2.46 | 1.12 | 9.9 | 252 | 6.2 (uncertainty: 1) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
4152-HL | 0.2 | 0.15 | 12000 | Rear | 5/16 in. - 24 Thread | 3/32 | 2.5 | 6 | 150 | Hook and Loop | Yes | Short | 1.92 | 0.87 | 7.48 | 190 | 7 (uncertainty: 2.2) | 81.6 | 5/16 | 8 | 1/4 NPT | 8 | 226 |
