Durable:
- These motors are able to work in even the most difficult environments.
Versatile:
- These motors can function at variable speeds and torques and come in both flange and foot mounting options.
Model | Max. Power (hp) | Max. Power (kW) | Reversible | Torque Stall (ft-lb) | Torque Stall (Nm) | Free Speed (rpm) | Torque Output @ Max. H.P. (ft-lb) | Torque Output @ Max. H.P. (Nm) | Speed at Max. Power (rpm) | Starting Torque (ft-lb) | Starting Torque (Nm) | Air Consumption at Max. Power (scfm) | Air Consumption at Max. Power (m³/m) | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Diameter/Width (in) | Diameter/Width (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
KK5B546 | 29 | 21.6 | Yes | 300 | 407 | 1800 | 150 | 203.37 | 900 | 183 | 248 | 795 | 22.5 | 251 | 113.9 | 16.65 | 422.9 | 17.88 | 451.2 |
KK5B550 | 30 | 22.3 | Yes | 325 | 441 | 1750 | 162.5 | 220.32 | 875 | 202 | 274 | 850 | 24.1 | 251 | 113.9 | 16.65 | 422.9 | 17.88 | 451.2 |
