QM3 Series Fixtured Spindles

QM3 Tools are highly durable designed. They come with flexible mounting options and are designed to work for Single or Multi Spindle Applications. QM3 Torque Range 0.8-20Nm.

Accuracy:

  • The closed loop transducerized control provides high accuracy and traceability for advanced torque control strategies.

Flexibility:

  • With flexible mounting options, an external electronics pod, and high durability cables and connections, you’ll be able to integrate your spindles with ease and security.

Reliability:

  • With a heavy duty gear train and brushless DC motor, the QM3 series is as dependable as it is efficient. And with preventative maintenance alarms, you’ll always know when your tool is in need of a tune up.

Model

Torque Range (Nm)

Torque Range (in-lbs)

Torque Range (ft-lbs)

Max Torque (Nm)

Free Speed (rpm)

Spindle Length (mm)

Float (mm)

Length (mm)

Length (in)

Weight (kg)

Weight (lbs)

C-C (mm)

Bolt Size

Square Drive (in)

QM3SS008H22S06

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M5

3/8

QM3SS008H22S08

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M5

1/2

QM3SS008H62S06

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M5

3/8

QM3SS008H62S08

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M5

1/2

QM3SS008H92S06

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

243.6

50

524

20.629921259842522

2.4

5.29

34

M4 - M5

3/8

QM3SS008H92S08

0.8-8

7.08-70.8

0.59 - 5.9

8

1382

243.6

50

524

20.629921259842522

2.5

5.51

34

M4 - M5

1/2

QM3SS012H22S06

1.2-12

10.62-106.2

0.9 - 8.8

12

927

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M6

3/8

QM3SS012H22S08

1.2-12

10.62-106.2

0.9 - 8.8

12

927

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M6

1/2

QM3SS012H62S06

1.2-12

10.62-106.2

0.9 - 8.8

12

927

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M6

3/8

QM3SS012H62S08

1.2-12

10.62-106.2

0.9 - 8.8

12

927

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M6

1/2

QM3SS012H92S06

1.2-12

10.62-106.2

0.9 - 8.8

12

927

243.6

50

524

20.629921259842522

2.5

5.51

34

M4 - M6

3/8

QM3SS012H92S08

1.2-12

10.62-106.2

0.9 - 8.8

12

927

243.6

50

524

20.629921259842522

2.5

5.51

34

M4 - M6

1/2

QM3SS016H22S06

1.6-16

14.16-141.6

1.2 - 11.7

16

686

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M6

3/8

QM3SS016H22S08

1.6-16

14.16-141.6

1.2 - 11.7

16

686

318.6

50

599

23.582677165354333

2.7

5.95

34

M4 - M6

1/2

QM3SS016H62S06

1.6-16

14.16-141.6

1.2 - 11.7

16

686

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M6

3/8

QM3SS016H62S08

1.6-16

14.16-141.6

1.2 - 11.7

16

686

168.6

50

449

17.67716535433071

2.4

5.29

34

M4 - M6

1/2

QM3SS016H92S06

1.6-16

14.16-141.6

1.2 - 11.7

16

686

243.6

50

524

20.629921259842522

2.5

5.51

34

M4 - M6

3/8

QM3SS016H92S08

1.6-16

14.16-141.6

1.2 - 11.7

16

686

243.6

50

524

20.629921259842522

2.5

5.51

34

M4 - M6

1/2

QM3SS020H22S06

2-20

17.7-177

1.5 - 14.7

20

545

318.6

50

599

23.582677165354333

2.7

5.95

34

M5 - M6

3/8

QM3SS020H22S08

2-20

17.7-177

1.5 - 14.7

20

545

318.6

50

599

23.582677165354333

2.7

5.95

34

M5 - M6

1/2

QM3SS020H62S06

2-20

17.7-177

1.5 - 14.7

20

545

168.6

50

449

17.67716535433071

2.4

5.29

34

M5 - M6

3/8

QM3SS020H62S08

2-20

17.7-177

1.5 - 14.7

20

545

168.6

50

449

17.67716535433071

2.4

5.29

34

M5 - M6

1/2

QM3SS020H92S06

2-20

17.7-177

1.5 - 14.7

20

545

243.6

50

524

20.629921259842522

2.5

5.51

34

M5 - M6

3/8

QM3SS020H92S08

2-20

17.7-177

1.5 - 14.7

20

545

243.6

50

524

20.629921259842522

2.5

5.51

34

M5 - M6

1/2
