Safety:
- Designed with one-way shutoff operation
Ergonomics:
- Adjustable capacity
- Adjustable stroke limiting capacity
Durability:
- Aluminum body
- Polyurethane hose
The Spring Balancer line from Ingersoll Rand® has been upgraded with new adjustments that take its fine-tuning capabilities and safety innovations up a notch and its tight space potential down to even smaller spots. Designed with greater durability and a higher weight capacity, these newly improved accessories will put even more spring, safety, and strength in your step.
Model | Capacity lb (kg) | Weight lb (kg) | Lift ft (mm) | Housing Material | Cable Material | NPT (in) | Air Consumption (cfm) |
|---|---|---|---|---|---|---|---|
BHR-8 | 0.88 - 1.76 (0.6 - 0.8) | 2.57 (1.17) | 4-1/4 (1295) | Aluminum | Nylon | 1/4 | 18.4 |
BHR-15 | 1.65 - 3.31 (0.75 - 1.5) | 2.6 (1.2) | 4-1/4 (1295) | Aluminum | Nylon | 1/4 | 18.4 |
BHR-25 | 2.65 - 5.51 (1.2 - 2.5) | 2.9 (1.34) | 4-1/4 (1295) | Aluminum | Nylon | 1/4 | 18.4 |
