0 Series Milling Motors

The 0-Series Milling Motors are equipped with an inline planetary gear that allows them to handle a variety of speeds and torques, as well as the ability to start and reverse instantly. Features increased side loading capabilities.

Request a Quote Request Service, Parts or Support

Durable
These milling motors can withstand harsh work environments with ease. Ideal for increased side loading applilcations such as milling and sawing.

Ease of Service
The 0-Series Milling Motors are easy to service, allowing you to spend more time on your work and less time making repairs.

Model	Max. Power (hp)	Max. Power (kw)	Reversible	Torque Stall (ft-lb)	Torque Stall (Nm)	Free Speed (rpm)	Torque Output @ Max. H.P. (ft-lb)	Torque Output @ Max. H.P. (Nm)	Speed at Max. Power (rpm)	Spindle	Air Consumption at Max. Power (scfm)	Air Consumption at Max. Power (m^3/m)	Air Consumption @ Free Speed (scfm)	Air Consumption @ Free Speed (L/s)	Sound Level @ Free Speed dB(A)	Weight (lb)	Weight (kg)	Length (in)	Length (mm)	Diameter/Width (in)	Diameter/Width (mm)	Gear Reduction	In Line Motor
8232-1	0.6	0.44	No	0.7	0.9	19000	0.35	0.4	9500	1/4 in. Maximum Collet Capacity	41	1.16	41	19.4	80	2.87	1.29	6.88	174.6	3.44	87.4	Single	Yes
8232-2	0.6	0.44	No	2.15	2.9	5700	1.075	1.5	2850	1/4 in. Maximum Collet Capacity	41	1.16	41	19.4	80	2.87	1.29	6.88	174.6	3.44	87.4	Single	Yes
8232-4	0.6	0.44	No	4.5	6.1	2800	2.25	3	1400	1/4 in. Maximum Collet Capacity	41	1.16	41	19.4	80	2.87	1.29	6.88	174.6	3.44	87.4	Single	Yes
8232-5	0.6	0.44	No	7.5	10.2	1650	3.75	5.1	825	1/4 in. Maximum Collet Capacity	41	1.16	41	19.4	80	3.62	1.63	8.19	208	3.44	87.4	Double	Yes
