5 Series Non-Reversible Inline

The 5 Series Inline have great Power to Weight Ratio. 5 series Non-reversible drills deliver quality and Performance for continuous drilling applications.

Durable

  • Made with high quality chuck, these drills are durable, long-lasting and able to withstand harsh environments.

Performance

  • With easy handling and an ergonomic design, these tools perform as well as you do, with a special small angle head for close quarter drilling.

User Experience

  • With a power-to-weight ratio optimized for user efficiency, you’ll be able to get through tasks quickly and with minimal fatigue.

Model

Actuation

Max. Working Torque (Nm)

Max. Working Torque (in-lb)

Free Speed (rpm)

Weight with Chuck (kg)

Weight with Chuck (lb)

Length with Chuck (mm)

Length with Chuck (in)

Bit Holder Capacity (in)

Bit Holder Capacity (mm)

Side to Center (mm)

Side to Center (in)

Sound Level dB(A)

Rated Power (hp)

Air Inlet

cfm

5LK1

Lever

3.4

30.1

3.1

0.91

2

206

8.1

1/4

6.35

20.32

0.8

74.6

0.4

1/4" NPT

16

5LL1

Lever

4.5

39.8

2300

0.91

2

206

8.1

1/4

6.36

20.32

0.9

72.3

0.4

1/4" NPT

15

5LN3

Lever

9.01

79.7

1000

1.5

3.3

239

9.4

3/8

9.53

20.32

0.8

75.6

0.4

1/4" NPT

15
