Durability:
Accuracy:
Performance:
Well-Balanced & Lightweight Design:
Model | Actuation | Torque Range (Nm) | Torque Range (in-lbs) | Free Speed (rpm) | Weight (kg) | Weight (lb.) | Length (mm) | Length (in) | Side to Center Distance (mm) | Side to Center Distance (in) | Spindle Type | Sound Level dB(A) @ Free Speed | Inlet Location | Air Inlet (NPTF/NPT) | CFM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
41PA10TPQ4-EU | Trigger + Push to Start | 1.7 - 9.0 | 15 - 80 | 1000 | 1.4 | 3.1 | 249 | 9.8 | 22 | 0.9 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 28 |
41PA10TSQ4-EU | Trigger Start | 1.7 - 9.0 | 15 - 80 | 1000 | 1.4 | 3.1 | 249 | 9.8 | 22 | 0.9 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 28 |
41PA16TPQ4-EU | Trigger + Push to Start | 1.7 - 6.8 | 15 - 60 | 1600 | 1.4 | 3.1 | 249 | 9.8 | 22 | 0.9 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 28 |
41PA8TPQ4-EU | Trigger + Push to Start | 1.7 - 11.3 | 15 - 100 | 800 | 1.4 | 3.1 | 259 | 9.8 | 22 | 0.9 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 28 |
41PA8TSQ4-EU | Trigger Start | 1.7 - 11.3 | 15 - 100 | 800 | 1.4 | 3.1 | 249 | 9.8 | 22 | 0.9 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 28 |
