M2 Series Air Die Grinder

The M2-Series industrial Grinders is offering high durability with a powerful motor and less maintenance, more productivity with the speed governor helping to maximize life time of the abrasive, an adjustable guard and a spindle lock feature. It also offers versatility with the different configurations and speed rating covered by the range. For sure with the M2-Series from Ingersoll Rand you will get more time to work and less time in maintenance.

Power:
  • The power-to-weight ratio on the M2 Series Die Grinders will help you tackle the biggest jobs.

Comfort:

  • An ergonomic body and lightweight composite housing increase the M2 Series’ ease-of-use.

Access:

  • Coming in straight, angle and extended configurations, the M2 Series Die Grinders give you easier access to hard-to-reach places.

Other Features:

  • Lube-free, 1hp high performance motors run cooler and longer for less maintenance and faster material removal - Suited for heavier-duty grinding, cutting, cleaning, and polishing applications
  • Speed-governed motors on this die grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity
  • Quick-change spindle-lock eliminates the need for additional tools
  • Optimized for general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, aerospace, and metal fabrication
  • Motor controller prevents over-speeding and manages airflow for efficient use

Model

Rated Power (hp)

Rated Power (kW)

Max Free Speed (rpm)

Output

Wheel Type

Weight (lbs)

Weight (kg)

Length (in)

Length (mm)

Air Consumption @ Free Speed (cfm)

Air Consumption @ Free Speed (L/min)

Exhaust

M2A120RG4

1

0.75

12000

Collet (1/4 in. and 6 mm)

Burr

3.56

1.62

8.94

227

17

481

Rear

M2A180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

3.56

1.62

8.94

227

25

708

Rear

M2H180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

14

396

Rear

M2H200RG4

1

0.75

20000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

17

481

Rear

M2H250RG4

1

0.75

25000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

25

708

Rear

M2X075RG4

1

0.75

7500

Collet (1/4 in. and 6 mm)

Sanding Drum (Mounted)

2.97

1.35

11.95

304

25

708

Rear

M2X180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

14

396

Rear

M2X200RG4

1

0.75

20000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

17

481

Rear

M2X250RG4

1

0.75

25000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

25

708

Rear
