R3130 & R3150 IQV20™ Cordless Ratchets

R3130, R3150

Ideal for a wide range of applications - from engine repair and under - car work to light industrial maintenance, repair & operations (MRO). Compatible with the IQV® 20 Series battery platform, the 3/8" R3130 and 1/2" R3150 cordless ratchets deliver the convenience of cordless with the power of air.

Available in the Following Kits:

R3130-K12: 3/8” Ratchet, (1) BL2012 2.5Ah Li-ion Battery, (1) BC1121 Charger & Case
R3130-K22: 3/8” Ratchet, (2) BL2012 2.5Ah Li-ion Battery, (1) BC1121 Charger & Case
R3150-K12: 1/2” Ratchet, (1) BL2012 2.5Ah Li-ion Battery, (1) BC1121 Charger & Case
R3150-K22: 1/2” Ratchet, (2) BL2012 2.5Ah Li-ion Battery, (1) BC1121 Charger & Case

Request a Quote Request Service, Parts or Support

Features

Performance

With 54 ft-lbs of maximum torque, the R3130 & R3150 cordless ratchet delivers the same kind of power you expect from an air tool.

Durability

Patent-pending metal and composite construction makes this tool lightweight, yet strong for easy operation and protection against repeated drops.
Ultra Strong Reinforced Handle engineered to withstand manual ratcheting and bolt breakaway even on the toughest bolts

Versatility

Battery power means greater portability

Proven engineered head is the same durable ratchet head used in our air-powered ratchet, so it stands up to the toughest professional use
All-metal gear train is robust, durable and optimized for maximum power and efficiency
Variable-speed switch with electronic brake provides maximum control of this cordless ratchet wrench and increases safety-depress trigger, drive stops spinning

Ergonomic handle and comfort grip offers the same reach as an air ratchet
Steel frame is designed to be strong and durable, to protect the interior components of this cordless ratchet wrench
Unique slim-line design provides easy access in tight spots; where you can get your arm, you can get your cordless ratchet wrench
3-year warranty

Model Specifications

Model

Voltage

Battery

Drive Size

Actuation

Free Speed

Recomm. Torque Range (ft-lb)

Recomm. Torque Range (Nm)

Max Torque (ft-lb)

Max Torque (Nm)

Sound Pressure/Power dBA

Vibration Level m/s2 (K)

Weight (lbs)

Weight (kg)

Weight w/Battery (lbs)

Weight w/Battery (kg)

Length w/ Battery (in)

Length w/ Battery (mm)

Head Width (in)

Head Width (mm)

Height (in)

Height (mm)

R3130

20V

BL2010

3/8

Variable Speed Trigger

225

10-45

14-64

86 / 97

2.7 (0.7)

3.5

1.6

2.3

17.5

445

1.57

1.73

R3130

20V

BL2005

3/8

Variable Speed Trigger

225

10-45

14-64

86 / 97

3.2 (1.0)

3.5

1.6

4.4

17.5

445

1.57

1.73

R3150

20V

BL2010

1/2

Variable Speed Trigger

225

10-45

14-64

86 / 97

2.5 (0.7)

3.5

1.6

2.3

17.5

445

1.57

1.89

R3150

20V

BL2005

1/2

Variable Speed Trigger

225

10-45

14-64

86 / 97

2.8 (0.7)

3.5

1.6

4.4

17.5

445

1.57

1.89

Documents

IQV20™ & IQV40™ Series Cordless Tools Brochure

R3000 Series Product Information

R3000 Series User Manual

R3000 Series Parts Information

Cordless Ratchet Wrench Safety Information
