- Reversible vane air motor for precise control
- Rugged design provides maximum durability and dependability
- Pendant control enables safer one-person operation
- For diesel engines with displacements up to 500 litres and gas engines up to 1000 litres
- 90 psig air operation produces more than 438 NM of torque
- Integral disc brake is always engaged when motor is not in operation to ensure safer, engine adjustments
- For diesel engines with displacements up to 500 litres and gas engines up to 1000 litres
Model | Reversible | Max Torque ft.-lbs. | Max Torque Nm | Max Pressure (bar) | Max Pressure psi | Speed at Max Power (rpm) | Weight lb | Weight kg | Integral Brake (y/n) | Flange | Pinions (y/n) | Pendant (y/n) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
T480PVRP-03-** | Yes | 322 | 438 | 6 | 90 | 65 | 58 | 26 | Yes | 03 | Yes | No |
T480PVRP-03-**P | Yes | 322 | 438 | 6 | 90 | 65 | 69 | 31 | Yes | 03 | Yes | Yes |
