Durability:
Accuracy:
Performance:
Well-Balanced & Lightweight Design:
Model | Actuation | Torque Range (Nm) | Torque Range (in-lbs) | Free Speed (rpm) | Weight (kg) | Weight (lb.) | Length (mm) | Length (in) | Side to Center Distance (mm) | Side to Center Distance (in) | Spindle Type | Sound Level dB(A) @ Free Speed | Inlet Location | Air Inlet (NPTF/NPT) | CFM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
41SC10LTQ4 | Lever Throttle | 1.1-9.0 | 10-80 | 1000 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC10PSQ4 | Push-to-Start | 1.1-9.0 | 10-80 | 1000 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC17LTQ4 | Lever Throttle | 1.1-6.8 | 10-60 | 1700 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC17PSQ4 | Push-to-Start | 1.1-6.8 | 10-60 | 1700 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC25LTQ4 | Lever Throttle | 1.1-4.5 | 10-40 | 2500 | 1.3 | 2.9 | 264 | 10.4 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC25PSQ4 | Push-to-Start | 1.1-4.5 | 10-40 | 2500 | 1.3 | 2.8 | 264 | 10.4 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC8LTQ4 | Lever Throttle | 1.1-11.3 | 10-100 | 800 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC8PSQ4 | Push-to-Start | 1.1-11.3 | 10-100 | 800 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
41SC17LTQ4-EU | Push-to-Start | 1.1-6.8 | 10-60 | 1700 | 1.4 | 3.1 | 277 | 10.9 | 20 | 0.8 | 1/4 in. Hex Quick Change | 78 | Std | 1/4 in. NPT | 20 |
