Model | Configuration | Actuation | Drive Size | Drive Type | Forward Torque (ft-lbs) | Blows per minute | Free Speed (RPM) | Impacting Sound Level dB(A) -- ISO15744 (pressure/power) | Free Speed Sound Level dB(A) -- CAGI/ANSI S12.41 (pressure/power) | Vibration Level m/s2 (K) | Weight (lbs) | Weight (kg) | Air Inlet | Min Hose Size (in) | Min Hose Size (mm) | PSI | Bar |
2940A1 | D-Handle | Outside Trigger | No. 5 | Spline | Ball Locking Mechanism | 850 | 5000 | N/A | 94.8 / 105.8 | 17.8 (3.4) | 22 | 9.98 | 1/2 in. | 3/4 | 19 | 90 | |
2940B1 | D-Handle | Inside Trigger | No. 5 | Spline | Ball Locking Mechanism | 850 | 5000 | N/A | 94.8 / 105.8 | 17.8 (3.4) | 22 | 9.98 | 1/2 in. | 3/4 | 19 | 90 | |
2940B2 | D-Handle | Inside Trigger | 1 in. | Square | Thru-Hole | 850 | 5000 | N/A | 94.8 / 105.8 | 17.8 (3.4) | 22 | 9.98 | 1/2 in. | 3/4 | 19 | 90 | |
2940P2 | Pistol | Trigger | 1 in. | Square | Thru-Hole | 810 | 3350 | N/A | 94.2 / 105.2 | 18.1 (5.6) | 22.9 | 10.4 | 1/2 in. | 3/4 | 19 | 90 |
