정확성:
폐쇄 루프형 변환기가 탑재된 제어장치가 고급 토크 제어 전략에 필요한 탁월한 정확도와 추적 기능을 제공합니다.
효율성:
QE2 피스톨 시리즈는 TactAlert, LED 헤드라이트 및 표시등 옵션 등과 같이 사용자 조작 환경을 개선하는 다양한 기능이 탑재되어 거의 혼란 없이 효율적으로 작업을 진행할 수 있습니다.
신뢰성:
이 피스톨 공구는 비접촉식 스위치, 중부하 기어 트레인 및 브러시리스 DC 모터 덕분에 탁월한 효율성과 신뢰성을 제공합니다.
다기능:
이 공구는 토크 출력, 바디 스타일, 구동 및 스핀들 타입을 선택할 수 있으므로 사용자의 응용 분야에 맞게 공구를 사용자 정의할 수 있습니다.
Model | Torque Range (Nm) | Torque Range (in-lbs) | Torque Range (ft-lbs) | Max Torque (Nm) | Actuation | Configuration | Free Speed (rpm) | Spindle Length (mm) | Float (mm) | Overall Length (mm) | Length (in) | Weight (kg) | Weight (lbs) | Drive (size/style) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
QE2PP002P11Q04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger + Push-to-Start | Pistol | 3000 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PP002P11S04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger + Push-to-Start | Pistol | 3000 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PP003P11Q04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger + Push-to-Start | Pistol | 2450 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PP003P11S04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger + Push-to-Start | Pistol | 2450 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PP005P11Q04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger + Push-to-Start | Pistol | 1700 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PP005P11S04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger + Push-to-Start | Pistol | 1700 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PP007P11Q04 | 1.3 - 6.5 | 11.5 - 57.5 | 1.0-4.8 | 7 | Trigger + Push-to-Start | Pistol | 1250 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PP007P11S04 | 1.3 - 6.5 | 11.5 - 57.5 | 1.0-4.8 | 7 | Trigger + Push-to-Start | Pistol | 1250 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PP010P11Q04 | 2.0 - 10.0 | 17.7 - 88.5 | 1.5-7.4 | 10 | Trigger + Push-to-Start | Pistol | 850 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PP010P11S04 | 2.0 - 10.0 | 17.7 - 88.5 | 1.5-7.4 | 10 | Trigger + Push-to-Start | Pistol | 850 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PS002P11Q04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger + Push-to-Start | Pistol | 3000 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PS002P11S04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger + Push-to-Start | Pistol | 3000 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PS003P11Q04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger + Push-to-Start | Pistol | 2450 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PS003P11S04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger + Push-to-Start | Pistol | 2450 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PS005P11Q04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger + Push-to-Start | Pistol | 1700 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PS005P11S04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger + Push-to-Start | Pistol | 1700 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PS007P11Q04 | 1.3 - 6.5 | 11.5 - 57.5 | 1.0-4.8 | 7 | Trigger + Push-to-Start | Pistol | 1250 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PS007P11S04 | 1.3 - 6.5 | 11.5 - 57.5 | 1.0-4.8 | 7 | Trigger + Push-to-Start | Pistol | 1250 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PS010P11Q04 | 2.0 - 10.0 | 17.7 - 88.5 | 1.5-7.4 | 10 | Trigger + Push-to-Start | Pistol | 850 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PS010P11S04 | 2.0 - 10.0 | 17.7 - 88.5 | 1.5-7.4 | 10 | Trigger + Push-to-Start | Pistol | 850 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PT002P10Q04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger Start | Pistol | 3000 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PT002P10S04 | 0.3 - 1.5 | 2.7 - 13.3 | 0.2-1.1 | 2 | Trigger Start | Pistol | 3000 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PT003P10Q04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger Start | Pistol | 2450 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PT003P10S04 | 0.6 - 3.0 | 5.3 - 26.6 | 0.4-2.2 | 3 | Trigger Start | Pistol | 2450 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
QE2PT005P10Q04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger Start | Pistol | 1700 | N/A | N/A | 250 | 9.84251968503937 | 0.66 | 1.46 | 1/4 in. Quick Change |
QE2PT005P10S04 | 1.0 - 5.0 | 8.9 - 44.3 | 0.7-3.7 | 5 | Trigger Start | Pistol | 1700 | N/A | N/A | 242 | 9.527559055118111 | 0.66 | 1.46 | 1/4 in. Square |
