QA6 Series Fixtured Inline Remote Adjustable Shutoff Air Nutrunner

The QA6 Series nutrunners are designed to work as hard as you do. These tools are equipped with a reverse ring positioned for maximum comfort, multiple mounting flange options and a standard 4” inline spindle that provides 19mm of float.

Request a Quote Request Service, Parts or Support

Accurate
Adjustable External clutch for Delivering Consistent Torque Results

Durability
Spend your time working, not waiting for repair. QA series has been tested for 1 Million cycles without failure

Easy to Maintain
The lube-free motor makes it easy to manage the upkeep nutrunner with just a spanner wrench.

Model	Actuation	Torque Range (Nm)	Torque Range (ft-lb)	Free Speed (rpm)	Weight (kg)	Weight (lb)	Length (mm)	Length (in)	Head Side to Center (mm)	Head Side to Center (in)	cfm	Spindle Type	Common Fastener Size	Sound (dBA)
QA6ASRS025NF41S06	Remote Start	12 - 25	8.9 - 18.4	700	2.61	5.76	454	17.9	34	1.34	36	3/8 in. Square	M6 - M8	82.5
QA6ASRS030NF41S06	Remote Start	15 - 30	11.1 - 22.1	585	2.61	5.76	454	17.9	34	1.34	36	3/8 in. Square	M8	82.5
QA6ASRS040NF41S06	Remote Start	20 - 40	14.8 - 29.5	435	2.61	5.76	454	17.9	34	1.34	36	3/8 in. Square	M8	82.5
QA6ASRS055NF41S08	Remote Start	25 - 55	18.4 - 40.6	315	2.62	5.78	454	17.9	34	1.34	36	1/2 in. Square	M10	82.5
