Model | Rated Power (hp) | Rated Power hp (kW) | Max Free Speed (rpm) | Orbit Diameter (in) | Orbit Diameter (mm) | Pad Diameter or Size (in) | Pad Diameter or Size (mm) | Pad Face | Vaccum Ready | Shroud Style | Weight (lbs) | Weight (kg) | Length (in) | Length (mm) | Vibration m/s2 (uncertainty K) | Sound Pressure/ Power dBA | Min Hose Size (in) | Min Hose Size (mm) | Air Inlet (in) | Air Consumption @ Free Speed (cfm) | Air Consumption @ Free Speed (L/min) | Air Consumption @ Load (cfm) | Air Consumption @ Load (L/min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
R026B-PSV-1 | 0.2 | 0.15 | 12000 | 3/16 | 5 | 6 | 150 | Vinyl | No | Short | 1.92 | 0.87 | 7.48 | 190 | 7 (uncertainty: 2.2) | 81.6 | 5/16 | 8 | 1/4 NPTF | 15.8 | 447 | 39 | 1105 |
R035A-CSV | 0.3 | 0.22 | 10000 | 3/16 | 5 | 5 | 125 | Vinyl | Yes | Short | 2.4 | 1.09 | 7 | 178 | 3.7 (uncertainty: 0.9) | 80 | 5/16 | 8 | 1/4 NPTF | 18.5 | 524 | 37 | 1048 |
R035A-PSV | 0.3 | 0.22 | 10000 | 3/16 | 5 | 5 | 125 | Vinyl | No | Short | 2.2 | 1 | 7 | 178 | 3.7 (uncertainty: 0.9) | 80 | 5/16 | 8 | 1/4 NPTF | 18.5 | 524 | 22 | 623 |
R036A-CSV | 0.3 | 0.22 | 10000 | 3/16 | 5 | 6 | 150 | Vinyl | Yes | Short | 2.4 | 1.09 | 7.48 | 190 | 4.3 (uncertainty: 1.4) | 80 | 5/16 | 8 | 1/4 NPTF | 18.5 | 524 | 37 | 1048 |
